· Application

  - The NPJ-MA is a magnet-type ratchet pusher designed to work safely and conveniently when thin plates and lightweight materials

     are placed on high walls or ceilings in the deckhouse outfit and various outfitting works of a ship or marine plant.

  - The NPJ-MH is a magnet-type jack pusher used to adjust the interval of frames when attaching side frames to the outer plating and the

     inner bottom plating of a ship.

· Features

  - NPJ-MA and MH are efficient products that increase workability by embedding a magnet in each frame so that it can be attached to the

     floor as well as walls and ceil.

  - The magnet built into the body is a permanent magnet that turns the handle of the magnet from side to side to activate the magnetic

     force on-off.

  - The NPJ-MA pushes the object away by operating the handle of the rachet pusher.

  - The NPJ-MH pushes the object away by operating the hand pump (sold separately) sold separately.

· How to use

Fix it and then operate the handle of magnet,

- NPJ-MA : Push up or down the pawl, fix it and then operate the handle.

- NPJ-MH : After connecting the hand pump to the hydraulic cylinder, operate slowly without exceeding the allowable pressure.

· Warnings

  - Do not exceed the rated capacity specified on the ratchet pusher.

  - Be careful that the magnet may fall off if there is a foreign substance on the surface where the magnet is attached or if the

    surface is not flat.
